Van Der Valk Raised Pilothouse 32m - NEW BUILD
Van Der Valk Raised Pilothouse 32m - NEW BUILD
The Raised Pilothouse 32m has a highly sophisticated look, combining an overall contemporary appearance with subtle classic touches. A truly elegant yacht with all of the hallmarks of quality associated with Van der Valk.
Once again, Van der Valk cooperated with Guido de Groot Design to create this series. This layout means that the wheelhouse position is elevated and the forward main deck area freed for comfort and hotel functions; for example, an impressive main-deck master stateroom, exquisite dining area or practical crew quarters.
The Raised Pilothouse 32m is optimised for the Volvo Penta IPS system, a joystick-operated pod-type boat drive system with counter-rotating forward-facing propellers. The series is also perfectly suited to a conventional shaft driven propulsion system.
The Raised Pilothouse 32m is built in semi-displacement, full aluminium (hard chine, moderate V hull design) design, but can also be built in a steel full displacement (hard-chine or round bilged) version. It can be built in any size between 85-132 ft (26-40m).
A full range of options are available. This includes a variety of mechanical, plumbing and electrical options, helm, navigation and electronics alternatives, and a comprehensive range of finish materials, textures and colours.
This boat can be semi-customised or fully customised to create a bespoke and personal yacht at your request.
PRICE: £POA
YOUR PURCHASE WILL EARN A LUXREWARD
YOUR PURCHASE WILL SUPPORT GOOD CAUSES VIA LUXGIVEBACK
DETAILS
Hull Type: Displacement
Hull Material: Steel
No. of cabins: 7
ENGINES
Engine 2x MTU 12V 2000M 96L 1920 1920Hp
Engine Year 2023
Engine hours
Fuel Diesel
Fuel Capacity 10000
Drive Type Shaft
DIMENSIONS
Length Overall (m) 32
Beam (m) 7.05
Draft (m) 2
Displacement (kg) 127000
Technical
Engine – 2 x MTU 12V 2000M 96L 1920 HP/1432 kW
Shaft and propeller – Stainless steel water lubr. duplex, VEEM Ultraskew 5-bladed propellers
Gearbox – ZF 3050V / Reduction 3.00:1
Bow and stern thruster – 60hp hydraulic proportional bow and stern thruster
Generators – 32Kw Northern Lights M944T
230/400 Volts
Semi-displacement hull
Moderate V, hard chine hull form
Aluminium hull and superstructure
LOA – 32m
LWL – 26.24m
Draft – 2m
Beam – 7.05m
Displacement – approx. 127 tons
Max Speed – 24 knots
Cruising Speed – 18 knots
Fuel Tank – 10,000L
Fresh water – 2500L
Holding tank – 2500L
Cabins – 1 owner, 1 VIP, 1 double guest,
1 twin guest, 3 crew cabins (5/6 person crew)
Classification – RINA:C+, Hull, MACH; Y class
Additional Options
Steel full displacement hull
Dynamic positioning systems
Multiple helm stations
Full navigation system
Stabilisers, bow and stern thruster
Fresh water maker
Generator, inverter, shore power and chargers
Air compressor
Full range of exterior surface materials, colours and treatments
Full range of interior surface materials, colours and treatments
Heating and air conditioning incl. underfloor
Entertainment and audio visual systems
Safety and alarm systems with GPS tracking
Full range of galley and comfort appliances
Above and below the water lights and lighting effects
Passerelle, gangway, tender crane options
Tender and support craft
About the Manutacturer - Van der Valk
A passionate yachtsman and water sport enthusiast, Wim van der Valk founded the company that bears his name in 1967 and remains the driving force behind it today. Since its inception, Van der Valk has built a rich heritage in both steel and aluminium motor yachts. The success of the first cabin and aft-cabin design cruisers measuring from seven to ten metres quickly attracted widespread acclaim from the yachting public.
Today, Van der Valk’s production facilities in Waalwijk (NL) produce only a select number of bespoke yachts every year. This ensures unrivalled quality and exclusivity for individual owners. Each and every yacht benefits from the strictest quality control and a first-rate construction process. Only after intensive sea trials and quality control procedures can boats leave the yard for delivery to their new owners.
Van der Valk owes its ongoing success over the decades to an unwavering dedication to key values such as reliability, cooperation and a forward-thinking approach. As a family-run company with a pedigree that spans generations, Van der Valk understands the value of keeping one’s word and creating yachts that stand the test of time. They abide by agreements made with customers, suppliers and staff; building yachts which function equally as well as they look. Partners and buyers are considered as family members – and this is reflected in excellent relationships and many repeat clients.
Head to places that intrigue you. In style, at speed and in comfort. Find your favourite hideaway then mobilise the zero speed gyroscopic stabilisation to fully relax and enjoy the view.
